High Quality Plastic Tube Filling And Sealing Machine

1.Semi-Automatic plastic tube filling sealing machine is mechanotronics mechanical-electrical integration,use multiple introduction technology and controlled by PLC,it can completelocal color code , filling , sealing and tube out automatically  simultaneously . The machine runs smoothly ,

2.Easy to control and size change over , suitable for producing paste products.

3. It has a  modern  shape , a strong  practicability and good  value for  process,it is widely used in toothpaste, ketchup , paste food , cosmetic ,hair-dyeing paste ,art palette and industry


Tube Filling And Sealing Machine Features:

1.Stainless steel volumetric dozing syringe and Teflon piston seals for accurate dosage

2.Tube lifting at filling station so that filling nozzle gets inserted inside tube during filling

3.Tail cutting by 'suck back' method to prevent dripping of product after filling

4. Hot air tool for plastic / laminated tubes (Leister make heater)

5.PID temperature controller for accurate control of hot air temperature

6.Air supply to air heater through independent blower

7.Batch code embossing facility within sealing jaws (by using negatively etched character type fount)

8. Trimming of plastic / lami tubes at the top end

9. Preset counter

10.No−Tube−No−Fill system

11.Control sensor for non ejected tubes

12.Low air pressure switch

13.Emergency stop

14.Fixed position machine stop

 Tube Filling And Sealing Machine Technical Parameters:
